Observer: Tony Donnangelo Date/time of observation: 2003/07/20 05:50 U.T. Site location: Tuscarora State Forest, Camp Site #52, PA, USA Site coordinates: N. 40°20’43.4” (40.34538°) W. 77°33’43.7” (77.56215°) Site elevation: 482 meters (1,583feet) Site classification: State forest wilderness area Instrument: 14.5” Starmaster Dob. Magnification: 267x (7mm Nagler T6) Moon's age: 20d 11:10, illuminated 60.1% Liberations: 6.6°; N/S 4.26°; E/W 4.99° Object: Curtius (crater) Crater size: 95x95km (58x58mi) Lunar ray coordinates: 4.0°E., 67.0°S. Rukl chart #: 73
It was a dark and storm-less night. No clouds were available to obscure the starlight piercing down from the heavens above. The day was warm (82° F., 28° C.) but humid. The temperature dropped rapidly as the suffocating sun began to set. The night-time low of 53° F. (12° C.) in the mountain air was welcomed and refreshing. There were periods of dew, some worse than others; our telescope optics and eyepieces were spared. Air turbulence, due to the jet stream surging overhead, was most evident while observing Mars and the Moon. A speckling hint of the Milky Way, before the end of astronomical twilight, showed promise of what was to be. Pardon me if I seem over exuberant and poetically pathetic, but it was one of the best nights we had for observing in south-central Pennsylvania since last November. It was a brutal winter, a horrendous spring, and summer only shows a little sign of mercy from the sky gods.
Dave Mitsky and I traveled to one of the dark sites we utilize that’s ~1 1/2 hours drive from the Hershey area. We arrived before dark and set up our equipment and camp. We had time to eat our dinner before it got dark. We observed many deep sky objects before concentrating on Mars rising above our horizon. The Moon rose at 4:08 U.T., but didn’t clear our horizon for almost an hour. We continued to observe Mars for approximately another hour before I trained my scope on the Moon.
I began my usual routine of making a quick scan of the lunar surface for light rays. I immediately saw three light rays occurring simultaneously: one in Julius Caesar, one in Lilius, and one in Curtius (A previous light ray reported in Curtius was a sunrise ray.). A few minutes later, Dave spotted another one. It was daunting trying to observe all these light rays at once, positively identify the craters, and make an observational report. Dave had a long day, and I was still suffering from the effects of sleep deprivation from observing on a previous night. Despite our mental impairment, we thoroughly enjoyed our observations of the lunar light ray fest. Dave hadn’t observed the ray in Julius Caesar before it disappeared because of its short duration. The multiple rays, caused by high mountain peaks, Dave found in Alexander were the most interesting of the observing session.
I submitted individual reports for each of the three light rays, and Dave submitted one for his. Most of the information will be repetitive. The rays in Curtius and Lilius were almost identical, except for their size.
Curtius was totally within the illumination of the sun. The floor was completely shadowed, except for the effects of the ray. The summit of the central peak was illuminated. The ray started from just east of the base of the central peak to the eastern wall. The shadowed eastern wall of the central peak caused a dark arc between the illuminated central peak and the ray. It was a narrow, slightly cone shaped beam of light ~30km. (19mi.) long. The ray was visible when I first started observing the moon, so would have begun some time earlier.
By 06:30 U.T., the ray shortened significantly. It now started midway between the central peak and the eastern wall and began broadening. Within 15 minutes, it began to look like a pie shaped wedge. At 07:00 U.T., it broadened further and was only a remnant of its former shape. It remained as such until I ended my observations of the moon at 08:00 U.T.
Site Longitude = +77.562 Site Latitude = +40.345 Site Elevation = +249.000 Reproducing Lighting For: 2003/7/20 at 05:50 U.T. Desired Solar Altitude = +3.088(Setting), Azimuth = +280.992 Feature = CURTIUS Feature Longitude: = +4.400 Feature Latitude: = -67.200 Average Co-longitude = 167.611 Moon's Altitude Restricted = Y Altitude = +5.000 degrees In the Time column, D=Daylight, T=Twilight ---- Moon's ---- -- Earth's -- Topocentric Topocentric -------- Sun's -------- UT Date Time Alt° Semi-Diam'' Long° Lat° Colong° Lat° Azim° 2003/07/20 05:50 +18.505 901.07 +4.487 +5.235 164.271 +1.382 +280.992
Description from Virtual Moon Atlas: Circular formation. Steep slopes supporting Curtius B to the North Curtius D to the North-East and Curtius E to the West. High walls in terraces overlapped by a crater to the East and a craterlet to the South. Flat floor supporting several craterlets whose 2 to the North-West. Small mountain with 3 summits off-center to the North-West. Nectarian period (From -3.92 billions years to -3.85 billions years).
